100% Oil Free Compressor for Pharma, Food & Other Application
Technical Specification ( Screw Air Compressor)
OF-10W | OF-15W | OF-20W | OF-25W | OF-30W | OF-40W | OF-50W | OF-60W | OF-75W | OF-100W | ||
---|---|---|---|---|---|---|---|---|---|---|---|
Item | Unit | Specification | Specification | Specification | Specification | Specification | Specification | Specification | Specification | Specification | Specification |
Rated exhaust pressure |
(KW) | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 |
Rated exhaust capacity |
min | 1.2/1.1/1.0 | 1.6/1.5/1.3 | 2.4/2.3/2.0 | 3.1/2.8/2.5 | 3.7/3.4/3.0 | 5.2/4.7/4.3 | 6.1/5.6/5.0 | 7.5/6.8/6.0 | 10.0/9.0/7.8 | 13.0/12.0/10.0 |
Water lubrication |
L | 20 | 20 | 27 | 27 | 27 | 40 | 40 | 40 | 100 | 100 |
Intake temperature |
C°
|
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
150 Under atmospheric pressure |
200 Under atmospheric pressure |
Exhaust temperature |
C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
Drive mode |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
RPM | rpm | 2940 | 2940 | 2940 | 2940 | 2940 | 2940 | 2940 | 2960 | 2960 | 2960 |
Rated powe | kw | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 75 |
Exhaust oil content |
ppm | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Cooling method |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
|
Noise Leve | dB(A) | 61 | 61 | 61 | 61 | 61 | 64 | 66 | 66 | 66 | 70 |
Outline size |
LxWxH (mm) |
1100×800 ×1000 |
1100×800 ×1000 |
1400×1000 ×1200 |
1400×1000 ×1200 |
1400×1000 ×1200 |
1920×1170 ×1320 |
1920×1170 ×1320 |
1920×1170 ×1320 |
1930×1320 ×1535 |
1930×1320 ×1535 |
Compressed air interface size |
G1〞 | G1〞 | G1〞 | G1〞 | G1〞 | G1½” | G1½” | G2” | G2” | G2” | |
Total weight | Kg | 480 | 500 | 520 | 520 | 560 | 1050 | 1050 | 1610 | 1610 | 1880 |
Rated power supply |
PH/V/HZ | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 |
Start-up mode | Y-∆ | Y-∆ | Y-∆ | Y-∆ | Y-∆ | Y-∆ | Y-∆ | Y-∆ | Y-∆ | Y-∆ | |
Rated exhaust pressure |
Technical Specification ( Screw Air Compressor)
OF-10WP | OF-15WP | OF-20WP | OF-25WP | OF-30WP | OF-40WP | OF-50WP | OF-60WP | OF-75WP | OF-100WP | ||
---|---|---|---|---|---|---|---|---|---|---|---|
Item | Unit | Specification | Specification | Specification | Specification | Specification | Specification | Specification | Specification | Specification | Specification |
Rated exhaust pressure |
(KW) | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 | 0.7/0.8/1.0 |
Rated exhaust capacity |
min | 1.2/1.1/1.0 | 1.6/1.5/1.3 | 2.4/2.3/2.0 | 3.1/2.8/2.5 | 3.7/3.4/3.0 | 5.2/4.7/4.3 | 6.1/5.6/5.0 | 7.5/6.8/6.0 | 10.0/9.0/7.8 | 13.0/12.0/10.0 |
Water lubrication |
L | 20 | 20 | 27 | 27 | 27 | 40 | 40 | 40 | 100 | 100 |
Intake temperature |
C°
|
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
2-40C° Under atmospheric pressure |
150 Under atmospheric pressure |
200 Under atmospheric pressure |
Exhaust temperature |
C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
ambient temperature +20C° |
Drive mode |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
Direct driven |
RPM | rpm | 2940 | 2940 | 2940 | 2940 | 2940 | 2940 | 2940 | 2960 | 2960 | 2960 |
Rated powe | kw | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 75 |
Exhaust oil content |
ppm | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Cooling method |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
Water cooling |
|
Noise Leve | dB(A) | 61 | 61 | 61 | 61 | 61 | 64 | 66 | 66 | 66 | 70 |
Outline size |
LxWxH (mm) |
1100×800 ×1000 |
1100×800 ×1000 |
1400×1000 ×1200 |
1400×1000 ×1200 |
1400×1000 ×1200 |
1920×1170 ×1320 |
1920×1170 ×1320 |
1920×1170 ×1320 |
1930×1320 ×1535 |
1930×1320 ×1535 |
Compressed air interface size |
G1〞 | G1〞 | G1〞 | G1〞 | G1〞 | G1½” | G1½” | G2” | G2” | G2” | |
Total weight | Kg | 480 | 500 | 520 | 520 | 560 | 1050 | 1050 | 1610 | 1610 | 1880 |
Rated power supply |
PH/V/HZ | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 | 3/415/50 |
Start-up mode | A/C Drive | A/C Drive | A/C Drive | A/C Drive | A/C Drive | A/C Drive | A/C Drive | A/C Drive | A/C Drive | A/C Drive | |
